Automatic Pallet Stretch Wrapper with Auto Film Clamper & Cutter

Automatic Pallet Stretch Wrapper with Auto Film Clamper & Cutter

Product Item:UCR-T1800Z
Type	Wrapping Machine
Condition	New
Application	Food, Beverage, Commodity, Chemical, Machinery & Hardware, APPAREL, Textiles
Automatic Grade	Semi-automatic
Voltage	220 VAC 1 ph 50/60 Hz
Brand Name	UCPACK
Dimension(L*W*H)	L 2700 mm × W 1800 mm × H 2500 mm
Certification	CE Certification
Packing Size Max.	L 2700 mm × W 1800 mm × H 2500 mm
Turntable Diameter	1800 mm
Load Capacity	2000 kg
Efficiency	20 - 40 loads/h
Turntable Height	100mm
Turntable Speed	0 - 12 rpm, variable
Power	1.55w
  • Product Detail
  • FAQs

Product Description

Cutting the Film Off and Tying it to the Next Pallet can Amount to Considerable Downtime During the Course of a Day's Pallet Wrapping. The Top-of-the-line Automatic Pallet Stretch Wrapper with Auto Film Clamper & Cutter Comes to do it for You

UCR-T1800Z Automatic Pallet Stretch Wrapper Comes Standard with a Remote Control and an Automatic Film Clamper & Cutter that
Automatically Cut the Film Off After Wrapping and Grip the Film for The Next Wrap.
Also Features a Dia. 1800 mm × 12 RPM Variable Speed Turntable with Max. 2000 kg Load Capacity, a Photoelectric Auto Load Height
Detector and a Powered Roller Pre-Stretch Film Delivery System Up to 250 - 300%.
Suitable for Max. W 1200 mm x L 1200 mm x H 2000 mm Pallet.

Also Available is the Loading Ramp to Enable Easy Loading of Pallets onto Turntable..

Specifications

Model

UCR-T1800Z

Turntable Diameter

1800 mm

Packing Size Max.

W 500 - 1200 mm × L 500 - 1200 mm

Turntable Height

100 mm

Turntable Speed

0 - 12 rpm, variable

     Automatic Film Clamper & Cutter

Std.

Load Capacity

2000 kg



Stretch Film

LLDPE Stretch Film in 500 mm width × 15 - 35 um thickness; Film Reel in 76 mm core diameter × Max. 250 mm OD

Voltage

220 VAC 1 ph 50/60 Hz

Pre-Stretch

Up to 250 - 300%

Power

1.55 kw

Machine Size

L 2700 mm × W 1800 mm × H 2500 mm

Machine Weight

700 kg



Options

* Loading Ramp;
* Top Press: Pneumatic Operated or Electric Operated Top Presser Optional;
* Scale + Display / Scale + Display + Printer;
* Power Supply Based on Country of Destination;
* M-Type Turntable for Hand Pallet Truck Loading & Unloading;
* Larger Turntable: Dia. 1800 / 2000 / 2200 / 2400 mm Turntable Optional;
* Increased Pallet Height: 2200 / 2400 / 2800 / 3000 mm Max. Packing Height Optional;
* Slewing Bearing Mechanism for Heavier Load Capacity Up to 3000 kg

UCR-T1800Z - 6.jpg
